Printable Area - Up to 16” x 19.6” (40.6 x 49.8 cm) with optional large platen
Print Head Technology - Ricoh piezo-electric drop-on-demand inkjet
Ink Chambers / Nozzles per Chamber - 4 Ricoh print heads; 8 channels / 192 nozzles per channel
Typical Print Speeds (10" x 8" graphic, light garment) - Speed: 27 seconds; Fine: 42 seconds
Resolution Settings - Super Speed: 600 x 300 dpi / 2 pass; Speed: 600 x 600 dpi / 4 pass; Fine: 600 x 600 dpi / 8 pass; Extra Fine: 600 x 600 dpi / 9 pass; Super Fine: 1200 x 1200 dpi / 16 pass
Ink - Genuine Ricoh-approved direct-to-garment water-based pigmented CMYK and white ink
Ink Delivery System - Advanced closed-loop delivery system; auto ink circulation system for white channels
Printable Substrates - 100% cotton and high-cotton blends; 100% light poly, up to 50/50 dark poly, wood, canvas. Hats, shoes, and other extended media coming soon
Table Height Adjustment - Precision manual adjustment up to 1.2” (3.0 cm)
Maintenance Features - Precise ink monitoring, auto ink maintenance system, automated print head cleaning, power purge system
Operating Environment - 59°F–90°F (15°C–32°C)
Connectivity - USB drive and Ethernet
Electrical Requirements - 100/120VAC, 50–60Hz, 0.65A max, 70 watts
Dimensions - 19.4” H x 52.2” L x 33.9” W
Weight - 242.5 lbs (110 kg)
Curing Temperatures & Times (Heat Press, conveyor times vary) - Light shirt (CMYK only): 356°F / 180°C, 40 sec; Dark shirt (white ink): 330°F / 165°C, 90 sec
Pretreatment - Genuine Ricoh-approved formulas; use HVLP Wagner sprayer or automatic sprayer in a separate room
Standard Table - Medium (Included): 12.6" x 18" (32 x 45.7 cm)
Optional Platens - Large: 16" x 19.6" (40.6 x 49.8 cm); Small: 10.5" x 13" (26.6 x 33 cm)
Required Operating System - Windows 10 (Pro, Enterprise), Windows 11, Windows Server 2016/2019
Recommended Graphics Application - Photoshop / Illustrator / CorelDraw / Action Illustrated
Supported File Types - TIFF, PNG, JPG, BMP, PSB, PSD (PDF, PS, EPS supported for non-bundle editions)
Minimum Processor & Memory - CPU: Intel Core i3-2100 / AMD Athlon II X2 340; RAM: 4GB
Computer Storage - Free disk space: 120GB
Display Resolution - 1280 x 1024
